Are you looking for the optimal towing capacity of your 2011 Ford F150? This article provides all the information you need to determine the maximum amount of weight a 2011 Ford F150 can safely pull.
With the widest selection of models, cabs, box configurations, and equipment of its class, the 2011 Ford F150 is a great choice for towing heavy loads. It features an integrated trailer brake controller, trailer tow mirrors, and a rearview camera for added convenience and safety.
The towing capacity of the 2011 Ford F150 ranges between 5,500 lbs to 11,300 lbs when properly equipped depending on the engine type, and cab configurations. With this impressive hauling capacity and its other features, the 2011 Ford F150 has set itself up as the preferable truck for towing and hauling needs.
Table of Contents
Key features
- Three cab styles – Regular, SuperCab, and SuperCrew
- Fully boxed ladder-style frame, strongest in its class, with hydroformed high-strength steel welded through-rail cross members for superior handling control and responsiveness
- Tuned shear-style body mounts help keep road vibration away from the vehicle body for a quiet and comfortable ride
- 4-wheel vented disc brakes with standard 4-wheel Anti-lock Brake System (ABS) and electronic brake force distribution for responsive, confident stops and exceptional control under hard braking
- Deep cargo boxes offering the largest capacity in their class, plus class-exclusive box side steps and tailgate steps for easy access
2011 Ford F150 Engine Options
There were four engines available for the 2011 Ford F150 pickup truck including 3.7L DOHC, 5.7L DOHC, 6.2L SOHC, and EcoBoost 3.5L DOHC engine.
| ENGINE | MAXIMUM POWER | MAXIMUM TORQUE |
| 3.7L DOHC 4V V6 Ti-VCT | 302 hp | 278 lb.-ft. |
| 5.0L DOHC 4V V8 Ti-VCT | 360 hp | 380 lb.-ft. |
| 6.2L SOHC 2V V8 | 411 hp | 434 lb.-ft. |
| EcoBoost 3.5L DOHC 4V V6 | 365 hp | 420 lb.-ft. |
2010 Ford F150 Towing Capacity Chart based on Engine Types
Before you can determine the towing capacity of your 2011 Ford F150, you will need to know the exact engine specifications. Generally speaking, these are determined by the engine size, type of drivetrain (two-wheel-drive or four-wheel-drive), and axle ratio.
| ENGINE | MAXIMUM TOWING CAPACITY |
| 3.7L DOHC 4V V6 Ti-VCT | 5,800 lbs |
| 5.0L DOHC 4V V8 Ti-VCT | 9,800 lbs |
| 6.2L SOHC 2V V8 | 11,300 lbs |
| EcoBoost 3.5L DOHC 4V V6 | 11,300 lbs |
2011 Ford F150 Towing Capacity Chart
[Regular Cab]
| ENGINE TYPE | 4×2 TOWING CAPACITY | 4×4 TOWING CAPACITY |
| 3.7L 4-Valve V6 | 5,500 lbs (126” Wb, and 3.55 Axle Ratio) 6,000 lbs (126” Wb, and 3.73 Axle Ratio) 5,600 lbs (145” Wb, and 3.55 Axle Ratio) 6,100 lbs (145” Wb, and 3.73 Axle Ratio) | 5,700 lbs (126” Wb, and 3.55 Axle Ratio) 5,800 lbs (145” Wb, and 3.73 Axle Ratio) |
| 5.0L 4-Valve V8 | 7,900 lbs (126” Wb, and 3.31 Axle Ratio) 8,300 lbs (126” Wb, and 3.55 Axle Ratio) 8,400 lbs (145” Wb, and 3.31 Axle Ratio) 9,800 lbs (145” Wb, and 3.55 Axle Ratio) | 7,600 lbs (126” Wb, and 3.55 Axle Ratio) 8,000 lbs (126” Wb, and 3.73 Axle Ratio) 8,200 lbs (145” Wb, and 3.73 Axle Ratio) |
| 3.5L GTDI V6 | 8,800 lbs (145” Wb, and 3.15 Axle Ratio) 9,800 lbs (145” Wb, and 3.55 Axle Ratio) 11,300 lbs (145” Wb, and 3.73 Axle Ratio) | 8,600 lbs (145” Wb, and 3.15 Axle Ratio) 9,800 lbs (145” Wb, and 3.55 Axle Ratio) 9,800 lbs (145” Wb, and 3.73 Axle Ratio) 11,300 lbs (145” Wb, and 3.73 Axle Ratio) |
[Super Cab]
| ENGINE TYPE | 4×2 TOWING CAPACITY | 4×4 TOWING CAPACITY |
| 3.7L 4-Valve V6 | 5,800 lbs (145” Wb, and 3.73 Axle Ratio) | 5,500 lbs (145” Wb, and 3.55 Axle Ratio) |
| 5.0L 4-Valve V8 | 8,100 lbs (145” Wb, and 3.31 Axle Ratio) 9,500 lbs (145” Wb, and 3.55 Axle Ratio) 9,500 lbs (163” Wb, and 3.73 Axle Ratio) | 7,800 lbs (145” Wb, and 3.55 Axle Ratio) 9,400 lbs (145” Wb, and 3.73 Axle Ratio) 9,300 lbs (163” Wb, and 3.73 Axle Ratio) |
| 3.5L GTDI V6 | 8,600 lbs (145” Wb, and 3.15 Axle Ratio) 9,800 lbs (145” Wb, and 3.55 Axle Ratio) 11,300 lbs (145” Wb, and 3.73 Axle Ratio) 11,300 lbs (163” Wb, and 3.73 Axle Ratio) | 8,400 lbs (145” Wb, and 3.15 Axle Ratio) 9,800 lbs (145” Wb, and 3.55 Axle Ratio) 9,800 lbs (145” Wb, and 3.73 Axle Ratio) 11,300 lbs (145” Wb, and 3.73 Axle Ratio) 11,300 lbs (145” Wb, and 4.10 Axle Ratio) 11,200 lbs (163” Wb, and 3.73 Axle Ratio) |
| 6.2L 2-Valve V8 | N/A | 6,000 lbs (133” Wb, and 4.10 Axle Ratio) |
[Super Crew]
| ENGINE TYPE | 4×2 TOWING CAPACITY | 4×4 TOWING CAPACITY |
| 3.7L 4-Valve V6 | 5,700 lbs (145” Wb, and 3.73 Axle Ratio) | 5,500 lbs (145” Wb, and 3.55 Axle Ratio) |
| 5.0L 4-Valve V8 | 8,000 lbs (145” Wb, and 3.31 Axle Ratio) 8,000 lbs (145” Wb, and 3.55 Axle Ratio) 9,400 lbs (163” Wb, and 3.73 Axle Ratio) 7,900 lbs (157” Wb, and 3.31 Axle Ratio) 7,900 lbs (157” Wb, and 3.55 Axle Ratio) 9,200 lbs (157” Wb, and 3.73 Axle Ratio) | 7,700 lbs (145” Wb, and 3.55 Axle Ratio) 9,300 lbs (145” Wb, and 3.73 Axle Ratio) 7,500 lbs (157” Wb, and 3.55 Axle Ratio) 9,100 lbs (157” Wb, and 3.73 Axle Ratio) |
| 3.5L GTDI V6 | 8,500 lbs (145” Wb, and 3.15 Axle Ratio) 9,800 lbs (145” Wb, and 3.55 Axle Ratio) 11,300 lbs (145” Wb, and 3.73 Axle Ratio) | 8,200 lbs (145” Wb, and 3.15 Axle Ratio) 9,700 lbs (145” Wb, and 3.55 Axle Ratio) 9,700 lbs (145” Wb, and 3.73 Axle Ratio) 11,300 lbs (145” Wb, and 3.73 Axle Ratio) 11,300 lbs (145” Wb, and 4.10 Axle Ratio) 8,000 lbs (157” Wb, and 3.15 Axle Ratio) 9,600 lbs (157” Wb, and 3.55 Axle Ratio) 9,600 lbs (157” Wb, and 3.73 Axle Ratio) 11,200 lbs (157” Wb, and 3.73 Axle Ratio) 11,200 lbs (157” Wb, and 4.10 Axle Ratio) |
| 6.2L 2-Valve V8 | 7,500 lbs (145” Wb, and 3.73 Axle Ratio) 11,300 lbs (145” Wb, and 4.10 Axle Ratio) | 7,200 lbs (145” Wb, and 3.73 Axle Ratio) 11,100 lbs (145” Wb, and 3.73 Axle Ratio) 8,000 lbs (145” Wb, and 4.10 Axle Ratio) |
Conclusion
To determine the maximum towing capacity of your 2011 Ford F150, you’ll need to consider several factors, including the cab configuration, engine size, and payload rating.
The truck’s gross vehicle weight rating (GVWR) also plays an important role in determining the maximum towing capacity. In addition, check with your Ford dealer or consult your owner’s manual for specific information about your truck’s maximum towing capacity.
Your 2011 Ford F150 can tow up to 11,300 lbs. depending on the cab configuration, engine size, and your payload rating. Before you hit the road, it’s important to know the different types of towing options available for your Ford F150.
The 2011 Ford F150 equipped with a 6.2L SOHC 2V V8, and 3.5L DOHC 4V V6 engine can offer a maximum towing capability of 11,300 lbs. Thanks to the powerful performance, and torque offered by the two aggressive engines.
There are three main types of towing: fifth-wheel towing, gooseneck towing, and bumper hitch towing. Each type of trailer requires a specific trailer hitch with its own weight capacity and configuration, so be sure to select the most appropriate type for your needs.
Some safety protocols for safe towing
- Follow Proper Safety Protocols When Towing with a Ford F150.
- Before you tow any load, be sure to review and adhere to your Ford F150 owner’s manual for the recommended towing procedures.
- Make sure both your truck and trailer are in good working order, including the proper air pressure in the tires.
- Check the hitch connection for safety and reliability.
- Always follow regional or state laws when towing, such as a maximum speed or distance from other vehicles on the road.
If you want to safely tow heavier loads with your Ford F150, you can equip your truck with tow packages. Consider adding a lift kit or traction bars to the suspension of your truck and trailer for enhanced performance.
You may also want to install performance brakes and replace the existing exhaust system on your F150 for improved stability and handling.
Additionally, installing transmission coolers provides better cooling for the transmission during long tows. With the right upgrades, you can get even more out of your 2011 Ford F150’s towing capacity!
It’s essential to test drive your F150 with its trailer before heading out for a long trip or haul. This will give you the opportunity to adjust any settings, check on the proper pressure in tires, and ensure that steering and brakes are working correctly.
Doing so will help you avoid potential problems while on the road, which could lead to putting yourself, your cargo, passengers, and other drivers in danger.
