The 2010 Ford F150 was one of the most powerful pickup trucks of its generation. It was available with a variety of models, and equipment options for towing and hauling the heaviest loads.
Talking about the build quality, the F150 was built with long-lasting durability and safety features. The towing performance was supported by the available trailer brake controller, trailer tow mirrors, rearview camera, and various other features.
The towing capacity of the 2010 Ford F-150 ranges between 5,100 lbs to 11,300 lbs depending on the engine type, and cab configurations.
Table of Contents
The 2010 Ford F150 was available in four different engine configurations as shown in the table below.
| ENGINE | MAX POWER | MAX TORQUE |
| 4.6L 2V V8 | 248 hp | 294 lb-ft. |
| 4.6L 3V V8 | 292 hp | 320 lb-ft. |
| 5.4L 3V V8 (Regular Gas) | 310 hp | 365 lb.-ft. |
| 5.4L 3V V8 (E85 Fuel) | 320 hp | 390 lb.-ft. |
Key features include
- Three cab configurations – Regular, SuperCab and SuperCrew
- Fully boxed frame construction with hydroformed high-strength steel welded through-rail cross members for superior handling control and responsiveness – strongest in its class
- Coil-over-shock front suspension, twin tube shocks at all four corners, and rack-and-pinion steering for outstanding steering response and performance
- 4-wheel vented disc brakes with standard 4-wheel Anti-lock Brake System (ABS) and electronic brake force distribution for responsive, confident stops and exceptional control under hard braking
- Deep cargo boxes offer the largest capacity in their class, plus class-exclusive box side steps and tailgate steps for easy access.
2010 Ford F150 Towing Capacity Chart based on Engine Types
Before you can determine the towing capacity of your 2010 Ford F150, you will need to know the exact engine specifications. Generally speaking, these are determined by the engine size, type of drivetrain (two-wheel-drive or four-wheel-drive), and axle ratio.
| ENGINE | MAXIMUM TOWING CAPACITY |
| 4.6L 2V V8 | 5,800 lbs |
| 4.6L 3V V8 | 9,500 lbs |
| 5.4L 3V V8 | 11,300 lbs |
2010 Ford F150 Towing Capacity Charts
[Regular Cab]
| ENGINE TYPE | 4×2 TOWING CAPACITY | 4×4 TOWING CAPACITY |
| 4.6L 2-Valve V8 | 5,400 lbs (126” Wb, and 3.55 Axle Ratio) 5,900 lbs (126” Wb, and 3.73 Axle Ratio) 5,500 lbs (145” Wb, and 3.55 Axle Ratio) 6,000 lbs (145” Wb, and 3.73 Axle Ratio) | 5,700 lbs (126” Wb, and 3.55 Axle Ratio) 5,800 lbs (145” Wb, and 3.73 Axle Ratio) |
| 4.6L 3-Valve V8 | 8,000 lbs (145” Wb, and 3.31 Axle Ratio) 8,400 lbs (145” Wb, and 3.55 Axle Ratio) | 7,700 lbs (126” Wb, and 3.55 Axle Ratio) 8,000 lbs (126” Wb, and 3.73 Axle Ratio) 7,700 lbs (145” Wb, and 3.55 Axle Ratio) 8,200 lbs (145” Wb, and 3.73 Axle Ratio) |
| 5.4L 3-Valve V8 | 8,000 lbs (145” Wb, and 3.15 Axle Ratio) 9,800 lbs (145” Wb, and 3.55 Axle Ratio) 11,300 lbs (145” Wb, and 3.73 Axle Ratio) | 7,700 lbs (126” Wb, and 3.31 Axle Ratio) 7,700 lbs (145” Wb, and 3.31 Axle Ratio) 8,600 lbs (126” Wb, and 3.55 Axle Ratio) 9,500 lbs (145” Wb, and 3.55 Axle Ratio) 11,300 lbs (145” Wb, and 3.73 Axle Ratio) 8,600 lbs (126” Wb, and 3.73E Axle Ratio) 9,500 lbs (145” Wb, and 3.73E Axle Ratio) |
[Super Cab]
| ENGINE TYPE | 4×2 TOWING CAPACITY | 4×4 TOWING CAPACITY |
| 4.6L 2-Valve V8 | 5,300 lbs (145” Wb, and 3.55 Axle Ratio) 5,800 lbs (145” Wb, and 3.73 Axle Ratio) | 5,500 lbs (145” Wb, and 3.55 Axle Ratio) |
| 4.6L 3-Valve V8 | 8,100 lbs (145” Wb, and 3.31 Axle Ratio) 9,500 lbs (145” Wb, and 3.55 Axle Ratio) | 7,900 lbs (145” Wb, and 3.73 Axle Ratio) |
| 5.4L 3-Valve V8 | 8,600 lbs (145” Wb, and 3.15 Axle Ratio) 9,800 lbs (145” Wb, and 3.55 Axle Ratio) 11,300 lbs (145” Wb, and 3.73 Axle Ratio) 11,300 lbs (163” Wb, and 3.73 Axle Ratio) | 8,300 lbs (145” Wb, and 3.31 Axle Ratio) 9,700 lbs (145” Wb, and 3.31 Axle Ratio) 11,200 lbs (145” Wb, and 3.55 Axle Ratio) 11,100 lbs (163” Wb, and 3.55 Axle Ratio) 9,700 lbs (145” Wb, and 3.73 Axle Ratio) 11,200 lbs (145” Wb, and 3.73E Axle Ratio) |
[Super Crew]
| ENGINE TYPE | 4×2 TOWING CAPACITY | 4×4 TOWING CAPACITY |
| 4.6L 2-Valve V8 | 5,200 lbs (145” Wb, and 3.55 Axle Ratio) 5,100 lbs (157” Wb, and 3.55 Axle Ratio) 5,700 lbs (145” Wb, and 3.73 Axle Ratio) 5,600 lbs (157” Wb, and 3.73 Axle Ratio) | N/A |
| 4.6L 3-Valve V8 | 8,100 lbs (145” Wb, and 3.31 Axle Ratio) 8,000 lbs (157” Wb, and 3.31 Axle Ratio) 9,400 lbs (145” Wb, and 3.55 Axle Ratio) 9,300 lbs (157” Wb, and 3.55 Axle Ratio) | 7,700 lbs (145” Wb, and 3.55 Axle Ratio) 7,600 lbs (157” Wb, and 3.55 Axle Ratio) 9,300 lbs (145” Wb, and 3.73 Axle Ratio) 9,200 lbs (157” Wb, and 3.73 Axle Ratio) |
| 5.4L 3-Valve V8 | 8,500 lbs (145” Wb, and 3.15 Axle Ratio) 8,400 lbs (157” Wb, and 3.15 Axle Ratio) 9,800 lbs (145” Wb, and 3.55 Axle Ratio) 9,700 lbs (157” Wb, and 3.55 Axle Ratio) 5,300 lbs (145” Wb, and 3.73 Axle Ratio) 11,300 lbs (145” Wb, and 3.73 Axle Ratio) 11,300 lbs (157” Wb, and 3.73 Axle Ratio) | 8,100 lbs (145” Wb, and 3.31 Axle Ratio) 8,000 lbs (157” Wb, and 3.31 Axle Ratio) 9,600 lbs (145” Wb, and 3.55 Axle Ratio) 9,500 lbs (157” Wb, and 3.55 Axle Ratio) 5,100 lbs (145” Wb, and 3.73 Axle Ratio) 11,200 lbs (145” Wb, and 3.73 Axle Ratio) 11,100 lbs (157” Wb, and 3.73 Axle Ratio) 9,600 lbs (145” Wb, and 3.73E Axle Ratio) 9,500 lbs (157” Wb, and 3.73E Axle Ratio) 11,200 lbs (145” Wb, and 3.73E Axle Ratio) 11,100 lbs (157” Wb, and 3.73E Axle Ratio) |
2010 Ford F150 Towing Features
The Ford F150 2010 models have a number of innovative towing features and technologies that can make hauling cargo safer and more efficient.
These include TowCommand®, Trailer Sway Control™, which adjusts the brakes and engine power when it senses the trailer wagging too much, and an available tailgate step for easier loading and unloading.
The towing capacity for the F150 depends on its various engine options; you can check the exact specifications in your owner’s manual.
Conclusion
The towing capacity of the 2010 Ford F150 4×4 models is higher than that of 2WD versions since they are equipped with larger tires and heavier suspension components.
When outfitted with a 4.6L or 5.4L V8 engine, the average towing capacity lies somewhere between 6,660 and 11,300 lbs. Maximum payload ratings for these models typically range from 1,400 to 3,550 lbs.
Additionally, it’s important to remember that these numbers can vary based on other factors such as the vehicle’s configuration and cargo weight in addition to the type of trailer being towed.
Follow Important Towing Safety Tips
When towing a trailer with your Ford F150, it’s always important to take the necessary safety precautions. Make sure that you have an appropriate receiver hitch and ball mount for the trailer and use a trailer hitch lock for added security.
Always make sure that your tires are properly inflated and that brakes meet factory specifications. Every time you’re preparing to tow, inspect your truck and its cargo capacity, and if in doubt, consult your owner’s manual or a qualified mechanic.
Choosing the right tow vehicle is essential to ensure that you don’t exceed the vehicle’s limits. The 2010 F150 can handle more than light-to-medium cargo, so it’s important to make sure that you get an engine that can handle the load you are carrying.
Consider how much weight your F150 needs to tow and choose an engine accordingly. Always bear in mind that the Ford F150 has a maximum payload rating of 3,300 lbs and you should never attempt to exceed this amount.
