2014 Ford F150 Towing Capacity with Charts

When it comes to towing capacity, the 2014 Ford F150 really stands out. With a maximum trailer tow package and an upgraded rear bumper and trailer tow mirrors, this truck is designed to tackle any challenge you put in front of it.

It also features an integrated trailer brake controller and 4WD models with neutral tow functionality, giving you complete control over your towing experience. Whatever your hauling needs may be, the Ford F150 is sure to meet them!

The towing capacity of the 2014 Ford F150 ranges from 5,500 lbs. to 11,300 lbs. depending on the cab configuration, engine specification, axle ratio, drivetrain, and other modifications.

Key features

  • Tuned shear-style body mounts help keep road vibration away from the vehicle body for a quiet and comfortable ride
  • 4-wheel vented disc brakes with standard 4-wheel Anti-lock Brake System (ABS) and electronic brake force distribution for responsive, confident stops and exceptional control under hard braking
  • Deep cargo boxes offering great capacity, plus best-in-class pickup box access – available steps on all three sides

2014 Ford F150 Engine Options

There are four powerful engines available for the 2014 Ford F150 including a 3.7L 4V DOHC V6, a 5.0L 4V DOHC V8, a 6.2L 2V SOHC V8, and a 3.5L 4V DOHC V6 EcoBoost.

ENGINEMAXIMUM POWERMAXIMUM TORQUE
3.7L 4V DOHC V6302 hp278 lb.-ft.
5.0L 4V DOHC V8360 hp380 lb.-ft.
6.2L 2V SOHC V8411 hp434 lb.-ft.
3.5L 4V DOHC V6 EcoBoost365 hp420 lb.-ft.

2010 Ford F150 Towing Capacity Chart based on Engine Types

ENGINEMAXIMUM TOWING CAPACITY
3.7L 4V DOHC V66,700 lbs
5.0L 4V DOHC V810,000 lbs
6.2L 2V SOHC V811,300 lbs
3.5L 4V DOHC V6 EcoBoost11,300 lbs

The 2014 Ford F150 was available in three different cab configurations: Regular, SuperCab, and SuperCrew. The superior handling and responsiveness of the truck are powered by the fully boxed ladder-style frame with hydroformed high-strength steel welded through-rail cross members.

[Regular Cab]

ENGINE TYPE4×2 TOWING CAPACITY4×4 TOWING CAPACITY
3.7L 4-Valve V65,500 lbs (126” Wb, and 3.55 Axle Ratio)
6,000 lbs (126” Wb, and 3.73 Axle Ratio)
5,600 lbs (145” Wb, and 3.55 Axle Ratio)
6,700 lbs (145” Wb, and 3.73 Axle Ratio)
5,700 lbs (126” Wb, and 3.55 Axle Ratio)
5,900 lbs (145” Wb, and 3.73 Axle Ratio)
5.0L 4-Valve V87,900 lbs (126” Wb, and 3.31 Axle Ratio)
8,300 lbs (126” Wb, and 3.55 Axle Ratio)
8,400 lbs (145” Wb, and 3.31 Axle Ratio)
9,800 lbs (145” Wb, and 3.55 Axle Ratio)
10,000 lbs (145” Wb, and 3.73 Axle Ratio)
7,600 lbs (126” Wb, and 3.55 Axle Ratio)
8,000 lbs (126” Wb, and 3.73 Axle Ratio)
8,100 lbs (145” Wb, and 3.73 Axle Ratio)
9,700 lbs (145” Wb, and 3.73 Axle Ratio)
3.5L GTDI V68,800 lbs (145” Wb, and 3.15 Axle Ratio)
9,800 lbs (145” Wb, and 3.31 Axle Ratio)
11,300 lbs (145” Wb, and 3.73 Axle Ratio)
8,500 lbs (145” Wb, and 3.31 Axle Ratio)
9,700 lbs (145” Wb, and 3.55 Axle Ratio)
9,700 lbs (145” Wb, and 3.73 Axle Ratio)
11,300 lbs (145” Wb, and 3.73 Axle Ratio)

[Super Cab]

ENGINE TYPE4×2 TOWING CAPACITY4×4 TOWING CAPACITY
3.7L 4-Valve V65,800 lbs (145” Wb, and 3.73 Axle Ratio)5,500 lbs (145” Wb, and 3.55 Axle Ratio)
5.0L 4-Valve V88,000 lbs (145” Wb, and 3.31 Axle Ratio)
9,500 lbs (145” Wb, and 3.55 Axle Ratio)
7,900 lbs (163” Wb, and 3.31 Axle Ratio)
9,300 lbs (163” Wb. and 3.55 Axle Ratio)
7,800 lbs (145” Wb, and 3.55 Axle Ratio)
9,400 lbs (145” Wb, and 3.73 Axle Ratio)
7,600 lbs (163” Wb, and 3.55 Axle Ratio)
9,200 lbs (163” Wb, and 3.73 Axle Ratio)
9,300 lbs (163” Wb, and 3.73 Axle Ratio)
3.5L GTDI V68,600 lbs (145” Wb, and 3.15 Axle Ratio)
9,800 lbs (145” Wb, and 3.55 Axle Ratio)
11,300 lbs (145” Wb, and 3.73 Axle Ratio)
8,400 lbs (163” Wb, and 3.15 Axle Ratio)
9,600 lbs (163” Wb, and 3.55 Axle Ratio)
11,300 lbs (163” Wb, and 3.73 Axle Ratio)
8,300 lbs (145” Wb, and 3.31 Axle Ratio)
9,700 lbs (145” Wb, and 3.55 Axle Ratio)
9,700 lbs (145” Wb, and 3.73 Axle Ratio)
11,300 lbs (145” Wb, and 3.73 Axle Ratio)
11,300 lbs (145” Wb, and 4.10 Axle Ratio)
8,200 lbs (163” Wb, and 3.31 Axle Ratio)
9,600 lbs (163” Wb, and 3.55 Axle Ratio)
9,600 lbs (163” Wb, and 3.73 Axle Ratio)
11,300 lbs (163” Wb, and 3.73 Axle Ratio)
11,100 lbs (163” Wb, and 4.10 Axle Ratio)
6.2L 2-Valve V8N/A6,000 lbs (133” Wb, and 4.10 Axle Ratio)

[Super Crew]

ENGINE TYPE4×2 TOWING CAPACITY4×4 TOWING CAPACITY
3.7L 4-Valve V65,700 lbs (145” Wb, and 3.73 Axle Ratio)N/A
5.0L 4-Valve V88,000 lbs (145” Wb, and 3.31 Axle Ratio)
8,000 lbs (145” Wb, and 3.55 Axle Ratio)
9,400 lbs (145” Wb, and 3.73 Axle Ratio)
7,900 lbs (157” Wb, and 3.31 Axle Ratio)
7,900 lbs (157” Wb, and 3.55 Axle Ratio)
9,300 lbs (157” Wb, and 3.73 Axle Ratio)
9,500 lbs (157” Wb, and 3.73 Axle Ratio)
7,700 lbs (145” Wb, and 3.55 Axle Ratio)
9,300 lbs (145” Wb, and 3.73 Axle Ratio)
7,500 lbs (157” Wb, and 3.55 Axle Ratio)
9,100 lbs (157” Wb, and 3.73 Axle Ratio)
9,200 lbs (157” Wb, and 3.73 Axle Ratio)
3.5L GTDI V68,500 lbs (145” Wb, and 3.15 Axle Ratio)
9,800 lbs (145” Wb, and 3.55 Axle Ratio)
11,300 lbs (145” Wb, and 3.73 Axle Ratio)
8,400 lbs (157” Wb, and 3.15 Axle Ratio)
9,700 lbs (157” Wb, and 3.55 Axle Ratio)
11,300 lbs (157” Wb, and 3.73 Axle Ratio)
8,100 lbs (145” Wb, and 3.31 Axle Ratio)
9,600 lbs (145” Wb, and 3.55 Axle Ratio)
9,600 lbs (145” Wb, and 3.73 Axle Ratio)
11,200 lbs (145” Wb, and 3.73 Axle Ratio)
11,200 lbs (145” Wb, and 4.10 Axle Ratio)
8,000 lbs (157” Wb, and 3.31 Axle Ratio)
9,500 lbs (157” Wb, and 3.55 Axle Ratio)
9,500 lbs (157” Wb, and 3.73 Axle Ratio)
9,600 lbs (157” Wb, and 3.73 Axle Ratio)
11,100 lbs (157” Wb, and 3.73 Axle Ratio)
11,100 lbs (157” Wb, and 4.10 Axle Ratio)
6.2L 2-Valve V87,500 lbs (145” Wb, and 3.73 Axle Ratio)
11,300 lbs (145” Wb, and 3.73 Axle Ratio)
11,200 lbs (157” Wb, and 3.74Axle Ratio)
7,300 lbs (145” Wb, and 3.73 Axle Ratio)
11,100 lbs (145” Wb, and 3.73 Axle Ratio)
8,000 lbs (145” Wb, and 4.10 Axle Ratio)
10,900 lbs (157” Wb, and 3.73 Axle Ratio)

Conclusion

We explored the towing capacity of the 2014 Ford F150 pickup truck along with complete towing charts.

The 2014 Ford F150 is capable of towing up to 11,300 lbs with the available maximum trailer tow package. Thanks to its 6.2L SOHC 2V V8 and 3.5L DOHC 4V V6 EcoBoost engines, the Ford F150 boasts an impressive towing capability.

This impressive capacity is further supported by features such as an integrated trailer brake controller, trailer tow mirrors, rearview camera, and neutral tow functionality for 4WD models. The F150 also includes an upgraded rear bumper to support its Built Ford Tough credentials for towing and hauling.

If you want to increase the towing capacity of your Ford F150, there are towing packages available including traction bars, transmission coolers, brakes, hitches, and more.

However, you need to give your vehicle a test drive before departing on a long haul so that all settings are adjusted accordingly in order to avoid potential problems while out on the open roads!

Some safety protocols for safe towing

  • You should not exceed a trailer weight of 5,000 lbs. when towing with bumper only.
  • Trailer tongue load weight should be 10% of the total loaded trailer weight.
  • The combined weight of the vehicle, and trailer must not exceed the GCWR (Gross Combined Weight Rating) mentioned in the vehicle manual.
  • F150 owners must carefully read, and review the owner’s manual before using their pickup truck for towing purposes.
  • The maximum towing capacity may only be achieved when the 2021 F150 is equipped with a powerful engine, Max Trailer Tow Package, required tires, wheels, and other towing accessories.
  • The towing capacity varies according to the vehicle configuration, cargo, number of passengers, availability of towing accessories, and other customizations.
